The Adjustable Accent Module (AAM) features a Ø 1.6″ × 3.2″ cylinder that rotates 360° and tilts 90°. The LED light source is coupled with TIR optics to provide beam angles of 21°, 30°, and 36°, producing up to 600 lumens. LED light source CCT options are 3000K, 3500K, or 4000K, available in either 80 CRI or 90 CRI.

The AAM module can be selected in either a white or black finish, and a honeycomb louver accessory is also available. The AAM driver is mounted above the cylinder inside the Squero housing and accepts universal input voltage (120–277 VAC), while providing 0–10V dimming control.

High-Efficiency Lambertian Optic (HLO) is engineered with reflective sidewalls that distribute LED output across the acrylic shielding. To accommodate the curves of Lumenwerx rounded fixtures, the HLO is equipped with proprietary SupremeGrip™ technology, which keeps the optic securely in place.

Matte Black Parabolic Louver

Matte Aluminum Parabolic Louver

The Miniature Reflector Optic (MRO) is composed of molded Total Internal Reflection (TIR) elements placed over the LED emitter, along with precise parabolic reflectors that further shield the light source. The resulting beam is soft and features a feathered edge.

The Micro Spot is a Ø7/8″ × 1 5/16″ adjustable spotlight that extends, retracts, rotates 360°, and tilts 90°. Its LED light source is coupled with a TIR refractor to provide beam angles of 25°, 35°, and 50°, producing up to 400 lumens. LED CCT options include 2700K, 3000K, 3500K, 4000K, and 5000K, available in either 80+ CRI or 90+ CRI. The Micro Spot is offered in white or black finishes. Its driver is mounted within the luminaire housing and accepts universal input voltage (120–277 VAC) with 0–10V dimming control.

Specular Aluminum

The Translucent Indirect Optic (TIO) is composed of a horizontal LED array with a translucent lens that masks pixelation from the diodes. The TIO provides a 100° indirect spread, making it ideal when the fixture is mounted farther from the ceiling.

The Widespread Asymmetric Indirect Optic (WAI2) offers an upward grazing effect with a 45° forward throw. It softly highlights the ceiling with uplight while distributing the required illumination throughout the rest of the interior space. To minimize glare and enhance visual comfort, the WAI2 is an ideal solution.

The Widespread Indirect Optic (WIO2) is a horizontal LED array with a widespread indirect micro-prismatic optic that offers an impressive 160° spread. The WIO2 provides even illumination for smooth ceiling brightness, achieving uniformity ratios of up to 2:1.

The Adjustable Accent Module (AAM) features a Ø 1.6″ × 3.2″ cylinder that rotates 360° and tilts 90°. The LED light source is coupled with TIR optics to provide beam angles of 21°, 30°, and 36°, producing up to 600 lumens. LED light source CCT options are 3000K, 3500K, or 4000K, available in either 80 CRI or 90 CRI.

The AAM module can be selected in either a white or black finish, and a honeycomb louver accessory is also available. The AAM driver is mounted above the cylinder inside the Squero housing and accepts universal input voltage (120–277 VAC), while providing 0–10V dimming control.

High-Efficiency Lambertian Optic (HLO) is engineered with reflective sidewalls that distribute LED output across the acrylic shielding. To accommodate the curves of Lumenwerx rounded fixtures, the HLO is equipped with proprietary SupremeGrip™ technology, which keeps the optic securely in place.

Matte Black Parabolic Louver

Matte Aluminum Parabolic Louver

The Miniature Reflector Optic (MRO) is composed of molded Total Internal Reflection (TIR) elements placed over the LED emitter, along with precise parabolic reflectors that further shield the light source. The resulting beam is soft and features a feathered edge.

The Micro Spot is a Ø7/8″ × 1 5/16″ adjustable spotlight that extends, retracts, rotates 360°, and tilts 90°. Its LED light source is coupled with a TIR refractor to provide beam angles of 25°, 35°, and 50°, producing up to 400 lumens. LED CCT options include 2700K, 3000K, 3500K, 4000K, and 5000K, available in either 80+ CRI or 90+ CRI. The Micro Spot is offered in white or black finishes. Its driver is mounted within the luminaire housing and accepts universal input voltage (120–277 VAC) with 0–10V dimming control.

Specular Aluminum

The Translucent Indirect Optic (TIO) is composed of a horizontal LED array with a translucent lens that masks pixelation from the diodes. The TIO provides a 100° indirect spread, making it ideal when the fixture is mounted farther from the ceiling.

The Widespread Asymmetric Indirect Optic (WAI2) offers an upward grazing effect with a 45° forward throw. It softly highlights the ceiling with uplight while distributing the required illumination throughout the rest of the interior space. To minimize glare and enhance visual comfort, the WAI2 is an ideal solution.

The Widespread Indirect Optic (WIO2) is a horizontal LED array with a widespread indirect micro-prismatic optic that offers an impressive 160° spread. The WIO2 provides even illumination for smooth ceiling brightness, achieving uniformity ratios of up to 2:1.
